The fixed fluidized bed drier is a set of high-efficient drying equipment designed on the basis of the advanced technology and many years' of service feedback. In this drier, solid particles suspend in drying medium and the contacting area between the fluid medium and solid is larger so the thermal capacity coefficient is higher. Also the thermal efficiency is higher because the violent agitation reduces intensively the resistance of the air film. The machine features stable running, easy operation and rigid structure.

Major Technical Parameters
Item FG-10 FG-15 FG-25
Bed area (m2) Cold bed: 2
Hot bed: 5
Cold bed: 2.91
Hot bed: 7.23
Cold bed: 3.5
Hot bed: 11.5
Weight (t) 2 3 5.2
Dimensions (mm)(LWH) 5.22.44.2 6.283.514.8 8.54.55.5
Output (t/h) 10 15 25
Installed motor power (kw) 4 4 5.5
Water separation ability 40.3% 40.3%
